Architectural Landscape LED Lighting Design Concept

The following points are the first to be identified in the overall consideration of landscape LED lighting design for buildings.

1: Direction of viewing

Buildings may be viewed from a variety of directions and angles, but generally we need to decide on a particular direction as the main viewing direction before we proceed with the design.

2: Distance

The distance at which a person is likely to be viewed. The distance will affect the clarity of the view of the façade and will also affect the decision on the level of illumination.

3: Surroundings and background:

The ambience and background will affect the amount of illumination required for the subject. If the surroundings are dark, a little light is needed to illuminate the subject; if the surroundings are bright, the light needs to be increased to bring out the subject.

The building may be visible from various directions and angles, but generally we need to decide on a particular direction as the main viewing direction before proceeding with the design.

The design of LED lighting in a building landscape can be broadly divided into the following steps.

1: Deciding on the desired lighting effect

The building itself may produce different lighting effects due to its different appearance, or more uniform, or stronger changes in light and dark; it can also be a more plain way of expression, or a more lively way of expression, all depending on the properties of the building itself to decide.

2: Choose the right light source

The choice of light source should take into account factors such as light colour, colour rendering, efficiency and longevity. Generally speaking, gold brick and yellow-brown stone are more suitable for warm light, and the light source used is high-pressure sodium or halogen lamps.

3: Determining the required illumination level

The illuminance required depends on the lightness of the surroundings and the shade of the façade material. Generally speaking, the secondary facade should be illuminated at half the level of the main facade, so that the difference in light and darkness between the two facades can give a three-dimensional impression of the building.

4: Choosing the right lighting

Generally speaking, square-shaped floodlight have a larger angle of light distribution; round-shaped floodlight have a smaller angle; wide-angle luminaires have a more even effect, but are not suitable for long-distance projection; narrow-angle luminaires are suitable for long-distance projection, but are less even when used at close range.

5: Calculation of illuminance and number of luminaires

After the above steps have been completed, the number of luminaires is determined by calculating the illuminance according to the chosen light source, luminaire and installation location, so that the effect after installation can be as close as possible to the desired one. The appearance of the building is expressed at night by the projection of light, and the resulting effect can be quite different from the feeling of daytime. Therefore, in the LED lighting project design, the effect does not necessarily have to be the same as the daytime effect, but it is important The important thing is to bring out the character of the building.
